Description

This portable wireless DMX512 transmitter and receiver set is designed to streamline stage and event lighting control by removing the need for long cable runs. Suitable for concerts, theatres, DJs, and live productions, it enables stable wireless communication between a DMX512 console and compatible lighting fixtures. With long-range digital transmission and rechargeable operation, it supports flexible installation in both fixed venues and mobile lighting setups. The compact housing and clear LED indicators make it practical for professional environments requiring efficient lighting control and simplified system layouts.

Key Features:

• Wireless DMX512 transmitter and receiver for cable-free lighting control
• Up to 400 metres communication range in open environments
• Rechargeable battery with up to 16 hours operating time
• Stable 2.4GHz GFSK modulation for consistent signal transmission
• Compact and portable design for stage, theatre and DJ use
• Built-in watchdog timer for automatic system restart
• Clear LED indicators for transmission and receiving status

Specifications:

• Shell colour: Silver
• Material: Stainless steel and ABS
• Input voltage: 5V DC ±5%
• Power consumption: 5W
• Communication band: 2.400–2.4835GHz ISM
• Modulation mode: GFSK
• Maximum transmit power: 23dBm
• Communication distance: Up to 400m
• Battery capacity: 600mA
• Charging time: Approx. 2.5 hours
• Operating time: Up to 16 hours
• Receiving sensitivity: -94dBm
• DMX interface: RS485
• Control channel: DMX512
• CPU: 32-bit ARM core
• Operating temperature: -40°C to 85°C
• Storage temperature: -65°C to 150°C
• Power cord length: 92cm

Package Contents:

• 1x Wireless DMX512 Transmitter and Receiver Set

Specifications

• Weight: 200gr
• Usage: Indoor & outdoor

Pros and cons

• Sustainably produced
• Ideal for everyday use
• May discolor in direct sunlight
