Description

Secure and manage your home or office entry with this 7-inch video door intercom system. The system features hands-free communication, a monitor, and remote door unlock functions, allowing you to see and speak with visitors clearly. Adjustable screen brightness, color, and volume provide optimal viewing in any lighting condition. Equipped with a 1MP camera, 90° viewing angle, and 4 infrared LEDs, it ensures reliable video monitoring even at night. Designed for surface mounting, the durable ABS and metal casing provides long-lasting performance while maintaining a sleek, modern look.

Key Features:

• Hands-free intercom with monitor and door unlock

• 7" TFT LCD display with adjustable brightness, color, and volume

• 1MP CMOS camera with 3.6mm lens and 90° viewing angle

• Night vision with 4 infrared LEDs (0.2–1.0m range)

• 25 customizable ringtones for incoming calls

• Surface mount installation with durable ABS and metal casing

• Operating temperature: -30°C to +60°C

• Connection distance up to 100 meters

Specifications:

Monitor Unit:

• Screen: 7" TFT LCD

• Resolution: 800 × 480

• Power Supply: AC 100–240V input, DC 15V 1500mA output

• Case: ABS plastic

• Dimensions: 210 × 134 × 23 mm

• Installation: Surface mount

Camera Unit:

• Sensor: 1MP 1/4" CMOS

• Lens: 3.6mm

• Night Vision: 4 infrared LEDs, effective range 0.2–1.0m

• Camera Angle: 90°

• Case: Metal with rain cover

• Dimensions: 125 × 50 × 27 mm

• Wiring: RVV 4-core connection

Package Contents:

• 1 × 7" Monitor Unit

• 1 × 1MP Camera Unit

• 1 × Power Cable

• 1 × User Manual

Specifications

• Weight: 200gr
• Usage: Indoor & outdoor

Pros and cons

• Sustainably produced
• Ideal for everyday use
• May discolor in direct sunlight
